UPUN 421006 Клемма пружинная UJ5-16

<p>Клеммная колодка с пружинной клеткой, номинальное напряжение: 800 В, макс. рабочий ток: 90 А, метод подключения: пружинное соединение, количество подключений: 2, диапазон обжима: 1,5 мм²-25 мм², AWG: 16-4, толщина: 12,2 мм, высота: 50,6 мм, цвет: серый, тип монтажа: TH35-7,5、TH35-15</p><br><div class="_20200320 _techParams"> <div class="table_resp"> <table class="table_ex_1 table_border big_top_bord" width="100%" ><tr class="border_bot"><td class="color_gray_2" width="50%">Packing unit (PCS)</td><td>30</td> </tr><tr class="border_bot"><td class="color_gray_2" width="50%">NW per piece(g)</td><td>35.4</td> </tr><tr class="border_bot"><td class="color_gray_2" width="50%">Layers</td><td>1</td> </tr><tr class="border_bot"><td class="color_gray_2" width="50%">Number of connections </td><td>2</td> </tr><tr class="border_bot"><td class="color_gray_2" width="50%">Rated cross section(mm²)</td><td>25</td> </tr><tr class="border_bot"><td class="color_gray_2" width="50%">Color</td><td>grey</td> </tr><tr class="border_bot"><td class="color_gray_2" width="50%">Insulation material</td><td>PA</td> </tr><tr class="border_bot"><td class="color_gray_2" width="50%">Flame retardant grade （UL94）</td><td>V0</td> </tr><tr class="border_bot"><td class="color_gray_2" width="50%">Rated voltage(V)</td><td>800</td> </tr><tr class="border_bot"><td class="color_gray_2" width="50%">Rated current(A)</td><td>90</td> </tr><tr class="border_bot"><td class="color_gray_2" width="50%">Temperature of insulation material</td><td>-40℃～+125℃</td> </tr><tr class="border_bot"><td class="color_gray_2" width="50%">Wire feed</td><td>Above the terminal</td> </tr><tr class="border_bot"><td class="color_gray_2" width="50%">Connection Method</td><td>Spring-cage connection</td> </tr><tr class="border_bot"><td class="color_gray_2" width="50%">Stripping length(mm)</td><td>18</td> </tr><tr class="border_bot"><td class="color_gray_2" width="50%">Solid conductors(mm²)</td><td>1.5-25</td> </tr><tr class="border_bot"><td class="color_gray_2" width="50%">Solid conductors AWG</td><td>16-4</td> </tr><tr class="border_bot"><td class="color_gray_2" width="50%">Stranded conductors(mm²)</td><td>1.5-16</td> </tr><tr class="border_bot"><td class="color_gray_2" width="50%">Stranded conductors AWG</td><td>16-4</td> </tr><tr class="border_bot"><td class="color_gray_2" width="50%">Operating temperature（℃）</td><td>-40℃～+105℃</td> </tr><tr class="border_bot"><td class="color_gray_2" width="50%">Ambient temperature (storage/transportation)（℃）</td><td>-25℃～+60℃</td> </tr><tr class="border_bot"><td class="color_gray_2" width="50%">Relative humidity</td><td>30％～90％</td> </tr><tr class="border_bot"><td class="color_gray_2" width="50%">Connection in acc. with standard</td><td>IEC 60947-7-1</td> </tr></table></div></div>
